Hikvision FTP Server Address – Configure “Hikvision FTP Server”

Here, I disclose to you how to make Hikvision FTP server address. FTP server a remote PC on which you can store the information by utilizing document exchange convention. So also, the CCTV FTP server is utilized to store the CCTV recording with a specific end goal to anchor the reinforcement. Hikvision FTP server address is the address of FTP server which can be configured in the Hikvision devices like NVR/DVR. The design of the CCTV FTP server is simple however you ought to see each progression painstakingly.

What is Hikvision FTP Server Address?

Hikvision FTP server address is the address of a remote PC on which you can store all your CCTV recording by utilizing the document exchange convention. It can be a local FTP server or an online FTP server. In local FTP server you needn’t bother with the web and essentially it is disconnected PC and online FTP server is a web benefit given by facilitating organizations and you should have a web to transfer the chronicle document of CCTV.

Why we require a Hikvision FTP server Address?

There are two principal motivations to utilize the Hikvision FTP server address. One is the security reason. Once in a while, the CCTV recording is extremely touchy extraordinarily when it requirements to confirm so when the CCTV recording put at FTP server then it is sheltered and effectively open. The second need emerges when you have to store your account for a significant lot of time.

What types of a record store in Hikvision FTP Server?

In Hikvision, you can put only the snapshot of the CCTV camera, not supporter the video recording. It is a drawback with Hikvision. While other companies such as TVT offers the complete video recording on the FTP server. So now we need a Hikvision FTP server address. The plus point with the Hikvision is, You can store your CCTV snapshot on the Google drive.

Free FTP Server address for Hikvision

  1. You can get a free FTP server on DriveHq.
  2. Google Drive

How to configure Hikvision FTP server address

When you have an FTP server then you will get four accreditation

  • FTP have address
  • The FTP username
  • FTP secret word
  • Port number

So get each of the four certifications and store and compose it at a protected place. Presently you require an FTP customer programming by which you can get to your FTP account. FileZilla is a decent FTP customer programming and it is free you can without much of a stretch download from here. Introduce it on your nearby PC.

Step 1.

Open FileZilla on your computer and a screen shown below

hikvision ftp server address



Step 2.

Now open your Hikvision device using. Internet Explorer. If you do not know how to do this please read this How to connect DVR to the computer.

Go to the Network>Advance Setting. Here you find an option FTP. Click on that and will find the screen below.



hikvision ftp server address

Step 3.

Unclick at the Anonymous option. Here you can fill Hikvision FTP server address and others credentials as shown in the picture above. Click on the Test button. If the server responds correctly then save it. Otherwise, you should the detail what you fill.

Step 4.

Go to the Storage option. In the Record Schedule fill all the boxes for permanent recording. Then go to the Capture option on top. Here you can set all the parameters for the picture for FTP server. Click on Save button after completing the Step

hikvision ftp server address

Final Step

Step 5.

Now you can start to find the snapshot on the Hikvision FTP server. Connect using FileZilla and check your FTP account. The image will be shown as in the image below.

hikvision ftp server address

So this is all about Hikvision FTP server address. If you have any question or suggestion please write to us in the comment box below.

cctv ftp server configuration for all DVR/NVR – CCTV cloud storage

how to configure hikvision dvr on internet. hikvision DDNS Setup

CCTV : 3 Major Problem That You Face In IP Camera Setup

Please follow and like us:

Hikvision firmware update tool.How to update hikvision firmware

Hikvision firmware update tool. In order to update the firmware, Hikvision provides some good tools. Here we are explaining how to use hikvision firmware update tool. We explain two methods here. Before starting, let’s know, what is firmware and why we update the device firmware.

What is firmware?

Basically, Firmware is a program written in hardware of the device in order to make the device functional. It saved in the read-only memory of the device and can be randomly accessed by the device. In simple words, it is like the BIOS system of the computer. Firmware is installed by the manufacturer at the time of manufacturing to provide an interface for the user.

Why we update the firmware.

To understand why we update the firmware understand why we update the android version of our mobile. Obviously, To get more features. In a similar way, we want to get more new features into all devices so we will update the firmware of the device. instead of this, sometimes we found the device is not working properly due to some error firmware or sometimes firmware has crashed so in that case also we have to update the firmware of the device.

Hikvision Firmware Update Tool

Mainly, there are two tools provided by hikvision.

1. Batch update tool.

By using this tool you can update the firmware of more than one device at the same time.

2. Trivial File Transfer Protocol (TFTP) tool

The second one is TFTP tool, this is mainly used when we want to flash the IP devices. Trivial File Transfer Protocol (TFTP) is old technology and easy to use.

Download Hikvision Firmware Update Tool

Batch Update Tool

Download TFTP Tool

Hikvision Device Firmware Download  (Select according to your device only)

Hikvision Firmware update using Batch Tool

Step 1:

Download the setup file of Batch Tool using the given link in the download section. Install it on your local computer. Now connect your device to the computer. (In case, You do not know  How to connect DVR to computer).

Now run the setup on the computer and your device will show you in the software like in the picture

hikvision firmware update tool

Step 2:

Select the device which you want you to update and click on add button as shown in above picture. It will ask you to put a password. Just enter the device password and click ok. Now the device will come in the upper section as shown in the picture below. Please notice that password should be correct.

hikvision firmware update tool

Step 3:

Select the device from the upper section and click update button as shown in the picture below

hikvision firmware update tool

Step 4:

It will ask you to a firmware file which is stored in the first step. Just give it the path of that file and that’s it.

hikvision firmware update tool

Step 5:

Wait for until process is complete. After completing the processing device will restart and now you got updated device.

hikvision firmware update tool

Hikvision Firmware update using TFTP

Step 1.

Download the TFTP Tool and the firmware (Hikvision Device Firmware Download )for your device.

Extract the TFTP tool using Winrar at the root of the hard drive.

hikvision firmware update tool

Step 2.

Connect the device to your computer via Lan cable. please make sure them at the same network series (using cross line connect the device to PC or using the switch).

Step 3.

Put the firmware in the same directory where TFTP exe file placed. In my case D: \TFTP. Now run the exe file on the computer(do not need to install). Please make sure firmware’s language is same as the device language.

hikvision firmware update tool

Step 4.

Alter the computer IP address to 192.0.0.128 and subnet mask is 255.255.255. 0.

hikvision firmware update tool

Step 5.

After the above setting, Reboot the IP device, and the automatic tool can detect the device, and update.

hikvision firmware update tool

Disclaimer: This is only for educational purpose. Do it at your risk. cctvdesk.com will not take any kind of responsibility. In above some picture are outsources and these are third party images

This is all about how to use Hikvision firmware update tool. We hope this information is helpful to yours. If you have any query or suggestion please write us in the comment box.



















Please follow and like us:

Hikvision password reset tool : how to reset hikvision password

Hikvision password reset tool. There are so many available methods for using the Hikvision password reset tool. Here, we are going to discuss the easiest way to use Hikvision password reset tool. Before starting let’s get some knowledge about Hikvision password reset tools.

What is Hikvision password reset tool?

Hikvision is the big name in CCTV industry and has so many good products. So it very necessary to provide a good technical assistance to its clients. Hikvision allows their users to download some kind of tools for their devices. Similarly, Hikvision provides some tools for resetting the device password called Hikvision password reset tool.

What is the tool available for Hikvision password reset?

  •  Batch configuration tool
  •  SADP Tool for Hikvision
  •  Hikvision IVMS Tool

Hikvision password reset tool

Method 1

How to Hikvision password reset using the Hikvision password reset tool

The best and easiest way to reset the Hikvision device password is using SADP tool. For using this tool there are some requirements. Please get all the required things before starting the procedure.

Requirements for using the Hikvision password reset tool SADP

  1. Windows Computer/Laptop
  2. Lan Cable
  3. Basic knowledge of computer

Step 1: Download the Hikvision password reset tool SADP

  • Click on this link to download SADP Tool
  • Install SADP Tool into your computer
  • Connect your device to your computer via Lan cable

Step 2: Run the SADP tool to your computer

Here, you got a list of connected device. In the list, you got some information about your device. You only need the current date of the device(DVR/NVR) and the serial number of the device.

Hikvision password reset tool

Step 3: write a mail to Hikvision support

Copy the Start Time and Device Serial No and send them to HIKVISION technical support. Here a list available for Hikvision technical support email ids according to your country or region find the correct mail id and mail the Date and the Serial number of the device.

After some time you got a return mail from Hikvision have some information including a date followed by a code. Save it

Hikvision password reset tool

Step 3: Click on Forget Password on SADP

Now come back to SADP on your computer. Now click on “forgot password”

Hikvision password reset tool

After clicking you got a pop-up and ask for security code. Enter the security code (got from email) and click on confirm button. Your device password has been set to the default password.

Hikvision password reset tool

Method 2

  1. Open the login screen where asks for the password directly to your DVR
  2. Clicking Left-bottom corner on screen 2-3 times
  3. you will find a serial number of your device (DVR/NVR)
  4. Mail this serial number along with current date and time at  Hikvision Support email.
  5. Then after 15-20 minutes, you will get a mail having a master password.
  6. Enter this master password into DVR.
  7. Note: This is valid for only one day.

how to reset the password of DVR CP Plus, Hikvision, TVT

Here we discussed about Hikvision password reset using Hikvision password reset tool. If you have any query of suggetion please write us in the commect box.















Please follow and like us:

Solved: hik connect connection failed step by step

hik connect connection failed step by step. If you find an error hik connect connection failed then here some steps to check what is actual problem and solution for that. Firstly you should know How to connect hikvision DVR to mobile. It is a complete step by step tutorial on how to use hik connect.

If you know that how to use Hik-connect and still an error Hik connect connection failed, then probably you are making some mistake. Generally, The problem is in the connection of device and the router. So before the start check all the connections made by you.

Step to resolve the error hik connect connection failed

Step 1: Check Cabling and Lan connectors

You should that LAN connectors are of cable are properly punched. To do this you should use an IP tool to check the connectors (if you have). I have not any tool for that then you could check it manually too. Check to the colour of the cable.

Step 2: Check device got an internet connection or not.

GO to Menu>Configuration>Network>General and check IP, Gateway & DNS in Device as per Your Router series

error hik connect connection failed

      • Check IP address is correct and according to the router series.
      • Check Subnet mask
      • Check Default gateway (most important)
      • Check Preferred DNS Server

Step 3: No IP address conflict

Check your device’s IP address is not in conflict with some other device.  The best way to analyse it, remove the Lan cable from DVR/NVR and ping the same IP of DVR/NVR. If a reply is still coming it means your DVR/NVR IP is conflicting with another device and you should change the IP address.

If you do not know how to ping a device then go to the computer connected to the same router and follow steps

      • Press window button
      • type CMD and hit enter
      • type ping 192.168.1.XXX(your device IP)  and hit enter
      • Check reply is coming or not

Step 4: Platform Access is enabled

Go to Menu>Configuration>Network>Platform Access and click on “Enable” (if not).

error hik connect connection failed

Step 5: Check for verification code is correctly typed

hik connect connection failed solution

Step 6: Check QR code scanned properly and status should be Online.

hik connect connection failed step by step

If still, an error hik connect connection failed then also check for following

      • Check port 8000 is not modified
      • IP address of the device is not blocked by router or firewall
      • Check MAC address is not blocked by router or firewall
      • QR code gives the device serial number
      • The Internet is working properly
      • Restart the device
      • Call Hikvision customer care.

We a complete guide how to connect hikvision to mobile. You can also read this.

We hope your problem hik connect connection failed has been resolved by these given steps. If you have any query and suggestion about this error “hik connect connection failed” please write us in the comment box.





Please follow and like us:

how to configure Hikvision IP camera with NVR

how to configure Hikvision IP camera with NVR? Here, Some steps are there for how to configure Hikvision IP camera with NVR. To add an IP camera with Hikvision NVR, firstly find the default gateway of the existing network(if any). Then define the IP address of each camera according to the default gateway. For example. If the default gateway is: 192.168.1.1 then camera IP must be: 192.168.1.80.

To find the default gateway Go to computer > Start>Run > cmd> type ipconfig

Steps for how to configure hikvision IP camera with NVR

The  NVR is a device by which you can connect the IP cameras and record the video of them and got the footage whenever you want. So before start how to configure Hikvision IP camera with NVR have a look at the summary of steps

Summary of steps how to configure Hikvision IP camera with NVR.

  • Step 1. Setting the IP Address of Network Camera
  • Step 2. Setting the IP Address of Network Camera
  • Step 3. Find a list of all IP cameras
  • Step 4. Adding the IP Cameras to NVR



Step 1. Download the required Hikvision tool

Download SADP or  iVMS-4200   from given link. After installing it run the setup.

Connect the IP camera to the computer directly

Open SADP, and it will detect the online network cameras in the LAN and list the device information including IP address, subnet mask, port number, device serial number, device version, etc.,

Step 2. Setting the IP Address of Network Camera

Now You can change the IP address of IP camera according to your network. For example, NVR IP address is 192.168.1.200 then IP camera address should be like 192.168.1.XXX. So change it accordingly.

Note: Default IP address of Hikvision IP camera is 192.0.0.64 and the port number is 8000. The default username is admin, and password is 12345.

Step 2. Adding the IP Cameras to NVR

Right-click the mouse at NVR screen when you in the live view mode to show the right-click menu of NVR.

how to configure Hikvision IP camera with NVR

Step 3. Find a list of all IP cameras

Here, Click on Add IP Camera and the following window will open

how to configure Hikvision IP camera with NVR

Step 4. Adding the IP Cameras to NVR

All cameras with same network series will be displayed in the list. Click the add button from the list to add the camera into the NVR.

Step 5. Find the live preview at NVR screen.

Now you can find all added cameras from the live preview.

how to configure Hikvision IP camera with NVR



This is all about how to configure Hikvision IP camera with NVR. If you have any query regarding Hikvision IP camera setup then you can write us in the comment box.

Please follow and like us:

how to configure hikvision dvr on internet. hikvision DDNS Setup

how to configure hikvision dvr on internet . Hello, here we are going to describe how to configure hikvision dvr on internet with the help of screen shots. Follow the step with us and get your hikvision dvr on internet. first 4 step is about how to configure hikvision dvr on internet and step 5 is about how to configure hikvision dvr on android mobile. This also includes hikvision port forwarding.

how to configure hikvision dvr on internet

Summary

  • Step1. Connect to computer
  • Step 2. Assign IP to DVR/NVR and configure DDNS
  • Step 3.  Open the router and setting
  • Step 4. Register with Hikvision
  • Step 5. HikvisionDVR on android mobile

Step 1:  Connect to computer

Connect your NVR / DVR to the router via a cat-6 or cat-5 cables.
Go to computer > Start>Run > cmd> type ipconfig

how to configure hikvision dvr on internet

here, you got Lan IP and default gateway. Your device IP must be in the same series of the gateway(Router IP).
For eg. If the default gateway is: 192.168.1.1
then device IP will be: 192.168.1.75
or
If default gateway is: 192.168.2.1
then device IP will be: 192.168.2.64

Step 2: Assign IP to DVR/NVR

Menu>Configuration>Network>General

  • Disable DHCP option
    Give an IP to the device according to the DVR/NVR according to the default gateway.
    Assign Preferred DNS server address

how to configure hikvision dvr on internet

Go to Menu>Configuration>Network>Extranet Access and update the following information

  • Disable ezviz cloud
    Enable DDNS
    DDNS type-HiDDNS / Hkddns / EasyDDNS
    Server address: asdev.hik-online.com
    Device domain name eg: hik_dvr, steve, or whatever you want.

how to configure hikvision dvr on internet

Now save this setting, no message will be displayed if registered successfully. If an error occurred, then the message will come “Communication to the server failed”. If an error occurred then you should check the Network setting.

Go to Menu>Configuration>Network>NAT and disable the UPNP and apply the settings.

how to configure hikvision dvr on internet

Step 3: Open router and setting

Hikvision Port forwarding

Put the default gateway(find in step 1) in the browser. It will ask for a username and password. Put correct Username and Password. Now try to find an option called DMZ. It generally presents in Advance setting or Applicatons.

Hikvision Port forwarding

Now put the DVR IP in the DMZ and apply the setting.

Now go to the link ping.eu. and Check whether ports 80, 8000 and 554 are open or not.

Hikvision Port forwarding

If ports are closed, go to the router page
Advance Setup>NAT>Virtual Server(or port forwarding) and Port forwarding using your device’s local IP.

Hikvision Port forwarding

Step 4: Hikvision DDNS setup

Open http://asdev.hik-online.com. In this site, If you have not any account then click to http://www.hik-online.com/view/user/regist and fill all the information.

how to configure hikvision dvr on internet

If you logged in the first time, it asks to select the country. The country cannot be changed once saved, so please select it prudently. The country should be same as your DVR or NVR. After registration a link will be sent to your registered mail id, click on the link for activation of your account.

Find an option ‘Device management’ and click on ‘Add’ option. Fill  Device name and serial number. If HTTP port of device was changed from 80, please enter new port in HTTP Port area.

how to configure hikvision dvr on internet

Now you can access the DVR by Device Link URL.

how to configure hikvision dvr on internet



Step 5. How to configure Hikvision DVR On Android Mobile

Follow the given step on how to configure Hikvision DVR On Android Mobile.

Download mobile app IVMS 4500 from Playstore of App store.

how to configure hikvision dvr on android mobile

Open app and click on manually adding.

how to configure hikvision dvr on android mobile

Put an Alias whatever you want. Take Register Mode HiDDNS. Server address will be www.hik-online.com.

how to configure hikvision dvr on android mobile

how to configure hikvision dvr on android mobile

Fill domain name what you created. Put username and password of DVR od NVR and click on Live Preview.

how to configure hikvision dvr on android mobile

Now you can view Hikvision DVR online via mobile.

how to configure hikvision dvr on android mobile



This is all about how to configure hikvision dvr on internet and how to configure hikvision dvr on android mobile. We hope this is helpful for yours. If you have any query and suggestion please write us in the comment box.



Please follow and like us:

How to connect hikvision DVR to mobile

How to connect Hikvision DVR to mobile? Here, I am going to show to you how to connect Hikvision DVR to mobile via P2P(cloud). It is quite easy to connect Hikvision DVR remotely and access it to your mobile. By using this, you can also connect Hikvision DVR to your computer or laptop. so let’s start from step

How to connect Hikvision DVR to mobile

Step 1



In first step just go to the menu and find the option ‘configuration’. Click on that and you will find the next option seems as below.hikvision dvr connect

At above screen you should do some work. Firstly enable the DHCP option. Second one is disable ‘DNS DHCP’  as shown in the picture above. In Preferred DNS Server just put ‘8.8.8.8’. ‘Alternate DNS Server you can leave empty.

Step 2

Now Go to ;Plateform Access ‘

In next step you find the following options.

How to connect hikvision DVR to mobile

Just Enable Hik-connect option and also enable ‘Enable stream encryption’ and it will ask for verification code to make . Just put a strong verification code and remember it.

How to connect hikvision DVR to mobile

How to connect hikvision DVR to mobile



Step 3

Now its time to install the mobile app. Its named ‘HIK-CONNECT’. Just install it and register your email . After registration login it app with your registered email and password. Now click on add device icon on app screen.

How to connect hikvision DVR to mobile

Step 4

Just scan the QR code available at ‘platform access option’

How to connect hikvision DVR to mobile

Final Step

Now Just press add button to your app and now work is done.

How to connect hikvision DVR to mobile

You can also see this guide.

This is all about how to connect Hikvision DVR to mobile. If you have any kind of query please feel free to yourself to ask us. We are willing to solve your problem so just ask in comments.



Please follow and like us:
Open

Close

Enjoy this blog? Please spread the word :)
